Production Introduction
High temperature resistance, less anti-slag and High processing accuracy, no pressure for cutting thick plates.
Smooth inner wall and smooth air flow and Fast cutting speed and high surface finish.
Surface anti-oxidation treatment, long service life.
Model
Double nozzle
Single nozzle
Diameter
32mm
32mm
Height
15mm
15mm
Thread
M14mm
M14mm
Caliber
0.8/1.0/1.2/1.4/1.5/1.6/1.8/2.0/2.5/3.0/3.5/4.0/4.5/5.0/6.0
0.8/1.0/1.2/1.4/1.5/1.6/1.8/2.0/2.5/3.0/3.5/4.0/4.5/5.0/6.0
Material
imported copper with chromeplated
imported copper
Single And Double
Choice of single and double nozzles
1.The single-layer nozzle is used for melting and cutting, and nitrogen is used as an auxiliary gas for cutting stainless steel and aluminum plates. The single-layer nozzle of 1.4-3.0mm can be used for efficient cutting.
2.The double-layer nozzle is used for oxidative cutting, with oxygen as auxiliary gas, for cutting carbon steel, and the 1.5-3.0mm double-layer nozzle can be used for efficient cutting.
Cutting nozzle caliber selection
1. Thin plates below 3mm, suitable for nozzles within 1.0mm.
2. 3mm-10mm thick plate cutting, suitable for 1.5mm nozzle .
3.When cutting plates of 10mm or more, nozzles of 2mm or more can be selected.
